- Modular
Can be connected on either PragmaFlex portable platform or PragmaPod remote-control platform.
- 32 channels + 4 Mono
Maximum flexibility with wide active apertures for various UT, PAUT and TOFD applications.
- 128 elements
Maximum PAUT flexibility and speed with multiplexing over 128 elements.
- 200V Pulsing
Sharp and snappy bipolar pulsing to inject as much acoustic energy in the material, for best possible sensitivity.
- 125 MHz to 1 GHz
Best-in-Class sampling for the highest signal definition in challenging applications. 125 MHz for PAUT and up to 1 GHz for Mono. Always in 16-bit A-scans.
- More than 2000 focal laws
Maestro beamformer capable of generating all the beams that are needed, for up to 16 groups.
- Superb Signal
Wide dynamic range with up to 92 dB of variable gain (TCG) and programmable digital filters, for the best SNR available.
- Ready for 3D, with up to 12 axis
Direct support for position tracking devices, from one-axis quadrature encoder to full-fledge laser 6DOF trackers.
