| Test Range | 2.5 mm to 10 meter (in steel). Fine mode adjustable in step of 1mm. |
| Velocity | 1000 m/s to 15000 m/s. In Hot Key mode it has 21 pre-set values.Fine mode adjustable in step of 1 m/s. |
| Delay | Up to 3 meter adjustable in 0.01, 0.1 or 1mm step. |
| Gain | 100 dB calibrated gain adjustable in 0.1, 0.5, 1, 2, 6 or 14 dB step. |
| Rejection | 0 to 125% FSH with LED indicator. |
| Rectification | Full wave rectified with filtering. |
| Frequency | 0.5 MHz to 15 MHz (Wideband). |
| Linearity deviation | Vertical: ±3%, Horizontal: ±0.5%. |
| Test Modes | Pulse echo and transmit/receive. |
| Probe Connectors | LEMO Size 00 (2 no’s). |
| Monitor | Dual gate adjustable in 1% of Screen width with Positive/Negative logic, |
| Gate Expand | Gate Expand modes. Expands Range to width of the gate. |
| A-Scan memory | 500 Trace Patterns can be stored, recalled or transferred to PC via USB port.A-Scan trace pattern can be directly stored on SD card or on External USB disk. |
| Calibration Set-up | 50 different calibration set-ups can be Stored and Recalled. |
| Software | ArjnSoft30 Interface software for Data transfer, Analysis, Reporting and Printing. |
| USB and SD card | External USB disk and Micro SD card (up to 32GB) ports provided for data storage. |
| Display | 5 inch Colour Wide VGA LCD/TFT display (800×480 pixel, size 108×64 mm) with higher resolution LCD for better signal representation and better visibility with different colour sets. |
| Reference A-Scan | Reference A-Scan pattern of standard test object can be saved and recalled in the background for easy comparison during testing. |
| Echo Dynamic | Echo Dynamic pattern display. |
| Dynamic DAC | Dynamic DAC curve can be Digitally plotted (Smooth parabolic curve) on screen with selectable additional offset curves from 0 to 14 dB in 0.1 dB selectable steps.DAC curve can be set as flaw monitor gate can be plotted using minimum 2 to maximum 10 points. |
| DGS | Defect size evaluation using predefined probe settings and custom probe set-ups,ERS (Equivalent Reflector Size) can also be displayed on the screen. |
| AWS | Built in Software for Evaluation of defects in accordance with AWS Specification D1.1. |
| Built-In UT Data Recording | Carries out 100 Hours of continuous /Dynamic A-Scan and B-Scan recording (in 8 GB SD Card) which can be replayed and analysed in Machine as well as PC. |
| Colour B-Scan | Real time Colour coded Un-Encoded B-Scan along with A-Scan on the Screen which can be transferred to PC, Also analysis of A-Scan and B-Scan can be done in the machine as well as PC |
| Digital Readout And Trig. Function | Thickness/Depth can be displayed in digital readout when using a normal probe and Beam path, Surface Distance and Depth are directly displayed when angle probe is in use. |
| Update Rate | 50Hz. |
| Power | Lithium-Ion Battery pack 7.4VDC, 5AH. External charger is provided to charge the battery without engaging the main unit. |
| Battery Life | 8 Hours on Full Charge |
| Charger | Input Voltage 100 to 240 VAC. Charge status indicator is provided. |
| Temperature | 0 to 55°C. |
| Size | 117 x 176 x 56 mm (HxWxD). |
| Weight | 800 gms with Li-Ion Battery. |
| Compliance | Ultrasound: EN 12668, ASTM E317 |
