| Test Range | 10mm to 1000mm (@5920 M/sec Steel Velocity equivalent) continuously variable. It can be adjusted with hot key for coarse range step. Horizontal linearity 1%. |
| Velocity | 1000m/s to 9999m/s. continuous adjustment. It can be adjusted using hot key in 7 preset values. |
| Delay | 0-1000mm Continuous variable. It can be adjusted using hot key in coarse delay step. |
| Gain | 0-80 db with 0.1,0.5,1,2,6,12 dB step selection. Vertical Linearity: 5% |
| Rejection | Linear type (0-99%) of full screen height, 1% step. |
| Rectification | Full wave rectified A-Scan. |
| Frequency | 0.2 to 20 MHz |
| No of channels | 16 channels with separate A-Scan traces, Any or all can be selected. |
| Test Modes | Pulse echo or transmit/receive. |
| Transmitter | Negative Square wave type. |
| Freeze/Peak Freeze | Current display Freeze and Peak freeze to create echo dynamic pattern. |
| Connector | BNC type connectors for all channels. |
| Monitor | Dual gate for each channel adjustable in 1% screen width with Positive/Negative logic, Gate Expand modes. |
| Gate Expand | Expands Range to width of the gate. |
| A-Scan memory (built-in) | 200 Multicolored A-Scan with calibration parameters with measured value. Using external USB pen drive virtually unlimited A-scan and Calibration set-ups can be stored. |
| Calibration Set-up | 100 calibration parameters set-ups. |
| Software | Suitable PC software provided to review/ print report of the stored A-scan files. |
| Display | TFT Color with LED backlight 152mm x 91 mm Viewing area, 800 x 480 pixels. All channels have separate base line with color selectable by user. |
| A-Scan Display | Envelop or filled A-scan Pattern. |
| DAC | Separate Dynamic DAC curve for each channel with additional -6 and -14 dB. DAC curve can be set as flaw monitor gate. Using 2 to 10 points DAC curve can be plotted. |
| Measurement | Echo amplitude, Sound path, Echo to Echo distance. When angle probe is used then using trigonometric functions it calculates and displays Surface and Depth distance of defect. |
| Measuring Unit | Millimeters. |
| PRF | Maximum 8000 Hz which varies in step of 50 Hz as per parameter set value due to Auto limiting. |
| Update Rate | 50Hz |
| Power Source | Operates on Built in Li-Ion rechargeable battery or on Mains using supplied charger. Operation time is 8 hours with fully charged battery. |
| Charger | Input Voltage 100 to 240 VAC. Charge status indicator is provided. |
| Battery charge status | Battery charge status by suitable LED indication on charger. |
| Battery Status | Battery status indicator with auto low battery shut down to protect battery. |
| Encoder | Positional encoder interface to indicate travel distance/position of probe. |
| Keyboard | User friendly with direct access to frequently used functions. |
| Operating Temperature | 0 to 55⁰ C. (For operation) |
| Dimensions | 247mm x 151mm x 70mm |
| Weight | Approx 2 Kgs. |
